Color Plated Galvanized Wedge Anchors for Concrete
Color Plated Galvanized Wedge Anchors for Concrete
Color Plated Galvanized Wedge Anchors for Concrete
Facebook Twitter Youtube Whatsapp

Color Plated Galvanized Wedge Anchors for Concrete

Color-plated galvanized wedge anchors for concrete are specialized fasteners designed for securing objects to concrete surfaces. These anchors are typically made of carbon steel and then galvanized to enhance their resistance to corrosion,The color plating provides an aesthetic touch, and in some cases, it can indicate different levels of corrosion resistance or grades of material.

Finish:Color plated galvanized

Material：Stainless Steel 304,Carbon Steel

Standard:DIN

Size:M6-M24

Sample:Free

Grade:4.8,8.8,10.9, 12.9

Category Tags , , , ,
Get A Free Quote

Color Plated Galvanized Wedge Anchors for Concrete Description

Color galvanized wedge anchor bolts are heavy-duty fasteners used to securely anchor objects to solid surfaces like concrete or masonry. The galvanization process involves coating the steel bolt with a protective zinc layer to prevent rust and corrosion, which makes it suitable for outdoor and industrial applications where moisture is a concern. The coloring adds an aesthetic element or helps in distinguishing different sizes, types, or performance grades..Our wedge anchors are available in multiple specifications, including American, German, and International standards.Welcome to inquiry.

Color Galvanized Wedge Anchor Bolts Size Chart

Wedge Anchor Bolts is primarily used for heavy-duty equipment, such as pipe rack hangers, seismic support brackets, glass curtain walls, elevator brackets, shelves, railings, and steel structures.Its design includes an expanding wedge that is inserted into a pre-drilled hole in concrete. By using a hammer or impact drill to drive the wedge anchor into the hole, and then tightening the screw to generate pulling force, the expanding wedge/conical compression clip expands to create friction, securing the anchor in place. <strong>Finish:</strong>As finished <strong>Material：</strong>Stainless Steel 304 <strong>Standard:</strong>DIN <strong>Size:</strong>M6-M24 <strong>Sample:</strong>Free
Specification L D S M DrillingSize
M6*50 50 6 M6*12*1.6 10 6
M6*60 60 6 M6*12*1.6 10 6
M6*75 75 6 M6*12*1.6 10 6
M6*100 100 6 M6*12*1.6 10 6
M8*60 60 8 M6*12*1.6 13 8
M8*70 70 8 M6*12*1.6 13 8
M8*75 75 8 M6*12*1.6 13 8
M8*80 80 8 M6*12*1.6 13 8
M8*90 90 8 M6*12*1.6 13 8
M8*100 100 8 M6*12*1.6 13 8
M8*115 115 8 M6*12*1.6 13 8
M10*70 70 10 M10*20*2 17 10
M10*75 75 10 M10*20*2 17 10
M10*80 80 10 M10*20*2 17 10
M10*90 90 10 M10*20*2 17 10
M10*100 100 10 M10*20*2 17 10
M10*120 120 10 M10*20*2 17 10
M12*75 75 12 M12*24*2.5 19 12
M12*100 100 12 M12*24*2.5 19 12
M12*110 110 12 M12*24*2.5 19 12
M12*115 115 12 M12*24*2.5 19 12
M12*120 120 12 M12*24*2.5 19 12
M12*140 140 12 M12*24*2.5 19 12
M12*150 150 12 M12*24*2.5 19 12
M16*100 100 16 M16*30*3 24 16
M16*120 120 16 M16*30*3 24 16
M16*140 140 16 M16*30*3 24 16
M16*150 150 16 M16*30*3 24 16

Specifications

MOQ 1 Pallet, 1 Ton or 3000USD
Material Stainless Steel ,Carbon Steel
Surface finish Galvanized
Sizes Custom Size,standard sizes
Technique Procedure Stamping,Bend,Cut,Threads rolling
HS Code 7318159090

Shipping and Payment Terms:

  • We generally ship cargos worldwide by sea. The goods will be in a shipping container when arriving at the port. You are responsible for picking up your shipment and customs clearance on your side.
  • We do accept small, urgent orders that need to be shipped by air.
  • We currently accept T/T & L/C.
  • Please contact us if you have any questions about shipping or payment, we will be happy to assist you.
